Product Details
Place of Origin: China
Brand Name: Gce Hv BMS
Certification: GB/T 16935.1 GB/T 17626.2 GB/T 17626.5 CE
Model Number: RBMSS20-160A-1228.8V
Document: GCE HV BMS 4U 1500V200ARBMS....0.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1 Sets
Price: Negotiable with toby@hngce.com
Packaging Details: 670*560*240mm Cartons
Delivery Time: 15 days after receive the payment
Payment Terms: T/T
Supply Ability: 2000 sets in one month
Features: |
DC&AC Dual Power Supply |
Rated Current: |
160A |
Max. Voltage: |
1500V |
Model: |
RBMS-S20-160A-1500V |
Master Bms Height: |
4U |
Max Current: |
160A |
Cell Monitoring: |
Individual Cell Voltage Monitoring |
Operating Temperature: |
-20°C To 50°C |
Battery Charge &discharge Management: |
Available |
Battery Temperature Management: |
Available |
IAP Upgrade: |
Available |
Communication Protocol: |
CAN/RS 485 |
Hmi Display: |
Supported |
Material: |
Iron |
Features: |
DC&AC Dual Power Supply |
Rated Current: |
160A |
Max. Voltage: |
1500V |
Model: |
RBMS-S20-160A-1500V |
Master Bms Height: |
4U |
Max Current: |
160A |
Cell Monitoring: |
Individual Cell Voltage Monitoring |
Operating Temperature: |
-20°C To 50°C |
Battery Charge &discharge Management: |
Available |
Battery Temperature Management: |
Available |
IAP Upgrade: |
Available |
Communication Protocol: |
CAN/RS 485 |
Hmi Display: |
Supported |
Material: |
Iron |
1.Application scenarios
◎ PV power plant storage ◎ Island off-grid energy storage ◎ optical storage charge integration applications ◎ UPS power supply
2. Product system overview
RBMS(Rack BMS)products are battery management systems developed for large-scale high-voltage battery energy storage system applications. It adopts distributed architecture, modular design concept, high configurability, easy assembly, debugging and maintenance, and is applicable to various battery energy storage systems with DC voltage above 1000V to 1500V. This product can be configured as a two-level architecture (BMU+RBMS) at least, which is suitable for 50KWh-200KWh occasions. It can form a three-level architecture (BMU+RBMS+SBMS) in combination with the industrial personal computer and the battery stack management software, and is suitable for 200KWh-2MWh occasions.
3. Main technical parameters of RBMS
